CENTRALE TERMICA
FILTRO RACCOGLITORE DI IMPURITA’ A Y 924
L
F
G
H
L2
L1
Filtro raccoglitore di impurità a Y 924.
Corpo e tappo in ottone, filtro in acciaio inox AISI 304, guarnizioni in PTFE.
Fluidi compatibili: acqua per impianti termici.
Pressione max di esercizio: 16 bar. Temperatura max di esercizio: 100 °C. Attacchi filettati: UNI ISO 228-1
CAPACITÀ
Ø FILTRANTE F L H L1 L2
CODICE ATTACCHI G mm mesh mm mm mm mm mm €
0365902 ● F - F 3/8” 10 220 (~ 60 µm) 9 46 31 1 2 5,844
0365903 ● F - F 1/2” 15 220 (~ 60 µm) 11 56 40 1 2 10,070
0365904 ● F - F 3/4” 20 220 (~ 60 µm) 11 67 46 1 2 15,320
0365905 ● F - F 1” 25 220 (~ 60 µm) 14 74 50 1 2 22,030
0365906 ● F - F 1 1/4” 33 220 (~ 60 µm) 15 96 67 1 2 43,460
0365907 ● F - F 1 1/2” 37 220 (~ 60 µm) 15 104 74 1 2 52,900
0365908 ● F - F 2” 47 220 (~ 60 µm) 18 125 90 1 2 92,300
0365909 ● F - F 2 1/2” 55 135 (~ 110 µm) 19 146 107 1,5 3 201,000
0365910 ● F - F 3” 70 135 (~ 110 µm) 21 170 123 1,5 3 240,000
0365911 ● F - F 4” 90 135 (~ 110 µm) 25 210 152 1,5 3 468,000
CESTELLO DI RICAMBIO PER FILTRO Y 924
CODICE CONF. DESCRIZIONE MISURA €
0191192 1 Cestello inox per filtro a Y in ottone 1/2” 1,298
0191193 1 Cestello inox per filtro a Y in ottone 3/4” 1,948
0191194 ● 1 Cestello inox per filtro a Y in ottone 1” 2,597
0191195 1 Cestello inox per filtro a Y in ottone 1”1/4 3,246
0191196 1 Cestello inox per filtro a Y in ottone 1”1/2 3,841
0191197 1 Cestello inox per filtro a Y in ottone 2” 7,738
0191198 1 Cestello inox per filtro a Y in ottone 2”1/2 12,880
0191199 1 Cestello inox per filtro a Y in ottone 3” 16,130
0191200 1 Cestello inox per filtro a Y in ottone 4” 22,570
