FUMISTERIA
MONOPARETE ACCIAIO INOX AISI 316L
E 55
H1
Hu Di
H2
55 90°
Di
DI HU H1 H2 E
CODICE CONF. DESCRIZIONE mm mm mm mm mm U.M. €
0825437 1 Allacciamento a 90°, con guarnizione premontata 60 273 162 111 85 NR 47,010
0824950 ● 1 Allacciamento a 90°, con guarnizione premontata 80 273 162 111 85 NR 49,480
0824951 ● 1 Allacciamento a 90°, con guarnizione premontata 100 273 162 111 95 NR 50,300
0824952 ● 1 Allacciamento a 90° 120 273 162 111 105 NR 55,100
0824953 ● 1 Allacciamento a 90° 130 273 162 111 110 NR 55,500
0824954 1 Allacciamento a 90° 140 273 162 111 115 NR 59,500
0824955 1 Allacciamento a 90° 150 273 162 111 120 NR 61,500
0824956 1 Allacciamento a 90° 160 273 162 111 125 NR 88,700
0824957 1 Allacciamento a 90° 180 440 245 195 135 NR 97,900
0824958 1 Allacciamento a 90° 200 440 245 195 145 NR 104,600
0824959 1 Allacciamento a 90° 250 440 245 195 170 NR 152,200
0824960 1 Allacciamento a 90° 300 440 245 195 195 NR 161,500
E 55
H1
Hu
80
H2
55
Di
DI HU H1 H2 E
CODICE CONF. DESCRIZIONE mm mm mm mm mm U.M. €
0824972 1 Allacciamento a 90° ridotto a Ø 80 maschio, con guarnizione prem. 80 273 162 111 85 NR 68,500
0824973 ● 1 Allacciamento a 90° ridotto a Ø 80 maschio, con guarnizione prem. 100 273 162 111 95 NR 82,800
0824974 ● 1 Allacciamento a 90° ridotto a Ø 80 maschio 120 273 162 111 105 NR 85,000
0824975 ● 1 Allacciamento a 90° ridotto a Ø 80 maschio 130 273 162 111 110 NR 87,400
0824976 1 Allacciamento a 90° ridotto a Ø 80 maschio 140 273 162 111 115 NR 90,600
0824977 1 Allacciamento a 90° ridotto a Ø 80 maschio 150 273 162 111 120 NR 93,400
0824978 1 Allacciamento a 90° ridotto a Ø 80 maschio 160 273 162 111 125 NR 100,400
0824979 1 Allacciamento a 90° ridotto a Ø 80 maschio 180 273 162 111 135 NR 114,100
0824980 1 Allacciamento a 90° ridotto a Ø 80 maschio 200 273 162 111 145 NR 118,300
0824981 1 Allacciamento a 90° ridotto a Ø 80 maschio 250 273 162 111 170 NR 137,800
0824982 1 Allacciamento a 90° ridotto a Ø 80 maschio 300 273 162 111 195 NR 158,800
